• Designer: Dick Vermeulen
• Builder: Maine Cat, Bremen, ME

• Hull Type: Catamaran with Twin Daggerboards
• Rigging Type: Fractional Sloop (Rotating Spar)
• LOA: 41' 6" / 12.65 m
• LWL: 40' / 12.34 m
• Beam: 23' / 7.01 m
• Displacement: 12,200 lb / 5,534 kg
• Max Draft: 7' / 2.13 m
• Min Draft: 2' 6" / 0.76 m
• Bridge Deck Clearance:  2' 8" / 0.81 m
• Mast Height: 59' 6" / 18.14 m

• Twin 29 HP Yanmar model 3YM30 FC diesels
• Fuel: 92 Gals / 348 L (Two 46 Gal tanks)
• Hours: Port - 515.3 / Starboard - 974.2
• Yanmar Saildrive: Good condition as sighted, no corrosion evident.
• Propellers: (2) Flex-O-Fold 2-blade bronze folding 17x12, Replaced 2024

• Fuel: 92 Gals / 348 L (Two 46 Gal tanks) [Tank Tender gauge in starboard forward office/cabin]
• Water: One 22 Gal / 83 L and One 46 Gal / 174 L tank in each hull for 136 Gal / 257 L total
• Holding: Two 20 Gal / 76 L tanks, one in each hull

• Mainsail: North Sails; High Roach Mainsail NPL Tour Xi Grey NorLam Xi11 Grey CRG (replaced 2023)
• Jib: Furling Jib with Battens NPL Tour Xi Grey NorLam Xi14 Grey CRG (replaced 2023)
• Screacher: New in 2012
• Spinnaker: Original to the boat (2006)
• Storm Trysail: 2006

• Jib Furler: Schaefer System 3100 jib furler
• Screacher Furler: Profurl Titanium screacher furler

• Mainsail: 715 ft² / 66.43 m²
• Jib: 281 ft² / 26.11 m²
• Screacher: 575 ft2 / 53.42 m²
• Asy. Spinn: 1200 ft2 / 18.58 m²

• GPS:. Raymarine e127 Hybrid Touch MFD chartplotter at helm
• Radar: Raymarine e127 Hybrid Touch MFD w/Raymarine RD418HD 4kw 18” radom antenna on aft deck antenna mast
• VHF: ICOM IC-M330G with GPS receiver (New 2024)
• Depth: Nexus NX2 Multi Control display on bridgedeck and in forward workshop w/ thru-hull transducer
• Wind Annemometer: Nexus NX2 Wind Data on bridgedeck
• Speed/Log: Nexus NX2 Multi Control display on bridgedeck and in forward workshop w/ thru-hull transducer
• Autopilot: Raymarine p70 display head w/hydraulic drive inside pedestal
• Compass: Ritchie Powerdamp 4 ½” on helm pedestal
• Misc: Garmin GPSmap 76Cx and GPS 72 hand held GPS units

• Batteries: New in 2018
 - (4) Lifeline GPL-8DL 12-volt AGM house batteries (2 in each hull)
 - (2) Lifeline GPL-8DL 12-volt AGM engine start batteries (1 in each hull)
 - (1) Deka Marine Master 24M5 12-volt AGM generator cranking battery
• Switches: (2) Blue Sea Systems rotary vapor proof on/off/combine switches
• Distribution Panel: Bass Products circuit breaker panels in each hull
• Meters: DC amps and volts on starboard hull panel
• Shore Power: Marinco 30A/125V connector and 50’ 30A/125V cord.
• Outlets: Number of Outlets w/GFCI protection to be added...
• Shore Power / Inverter / Generator selector switch
• Meters/Indicators: AC amps on starboard hull panel; Mastervolt Mass inverter charger control panel
• Inverter: Mastervolt MASS/SINE 12/2000, 2000-watt inverter.
• Battery Charger: Mastervolt Powercharger 12/40-3 40-amp charger
• Solar Panels: (4) Mitsubishi Electric 110-watt solar panels model PV-MF110EC3 w/charge controller.
• Wiring: Marine grade insulated stranded copper wire, well routed.

• Make: 2.9KW Mase IS 4.0S (2006)
• Voltage: 120V / 60Hz / 24.1A
• Location: Starboard deck/anchor locker in rigid sound shield
• Cooling System: Raw water thru intercooled / air-cooled heat exchanger

• Air Conditioning: Mermaid 9,000 BTU model M-9CHP-T in each cabin.
• Watermaker: Spectra 12-volt DC watermaker
• Entertainment Center: Sony CDX-GT400 AM/FM/CD/AUX w/ speakers on bridgedeck

• Bridgedeck Salon and Pilot House:
• Dinette table forward with cushioned bench seats; winches with line clutches and line cubbies outboard
• Companionway access to port and starboard hulls outboard w/pocket sliding doors
• Helm station pedestal center w/adjustable pedestal helm seat and adjustable swiveling pedestal captains seats on port and starboard
• L-shaped cockpit bench seating aft on port and starboard with sheet winches center aft

• Port hull:
• Single v-berth forward; wet head next aft; double berth inboard w/storage cabinets below; galley aft

• Starboard hull:
• Single v-berth forward with work desk / nav station aft; double berth inboard w/storage cabinets below; cabinets and head with shower stall aft. All lights, outlets and fans replaced in 2023.

• Toilets: Lavac manual in port and starboard heads w/Gibb Henderson MKIV manual pumps.

• Showers: Handheld in port head and starboard head shower stall and by starboard stern boarding steps,

• Stove: Propane Force10 stainless steel 3-burner with oven
• (2) aluminum bottles in cockpit propane locker, port aft
• SeaFrost Fridge / Freezer (New 2024)
• Water Heater: (2) Isotherm Slim B 25-liter, model HXC25MV
• Pressure Water: (2) Shurflo Smart Sensor 4.0 model 4901-0201

• Mast & Boom: Selden anodized aluminum single spreader mast and Selden anodized aluminum boom
• Crossbeam: Aluminum crossbeam w/ aluminum A-frame support and S/S stays
• Bowsprit: Painted aluminum bowsprit
• Standing Rigging: 1x19 316 S/S wire shrouds and diamond stays, single set airfoil spreaders, S/S swaged end fittings, chromed bronze open barrel turnbuckles.
• Running Rigging: All lines, sheets and halyards recently replaced (2022-2024)
• Winches: All Lewmar Winches
 - (2) # 50ST 2-speed on aft combing mainsheet/genoa sheet/traveler
 - (2) #50ST 2-speed on forward housetop for daggerboards/halyard/furlers/jib/reefs (electric on starboard)
 - (1) #40ST 2-speed on portside mast.
• Deck Hardware:
 - Lewmar main and jib travelers w/Lewmar control blocks
 - Lewmar deck blocks
 - Rutgerson deck blocks at base of mast
 - Spinlock line clutches
• Steering: Stainless Steel wheel at pedestal with Edson rack and pinion gear to solid aluminum shafts w/greased ball and cup connectors.
• Stainless steel tube davit for outboard w/block and tackle hoist system
• Dinghy hoist system with retractable pole inside boom for hoist system
• Dinghy chocks off stern
• Painted aluminum antenna mast secured in structurally reinforced FRP tube on starboard stern w/ radar antenna and outboard davit.
• Custom stainless steel boom gallows on hardtop.
• Chainplates: ½” S/S plate fabrication bolted to hull sides.

• EPIRB: ACR Global Fix 406Mhz GPS model RLB-35 Cat2, UIN: 2DCC444B30FFBFF (Battery replaced 2022)
• PFDs: 9 X Type I (adult)
• Life Ring
• Lifesling for MOB
• Fire Extinguishers: (3) Kidde ABC model H110G on helm pedestal, by galley in port hull and by steps in starboard hull.
• Flares: Orion orange distress flag and Orion flares kit with 4 hand held red rockets, 2 orange smoke and revolver w/aerials
• First Aid Kit: Yacht Lifeline medical kit
• Sound Signals: Hand held air horn canisters
• Wooden Plugs: Assorted tapered wooden plugs stowed
Emergency steering: S/S emergency tiller in portside propane locker on bridgedeck

• All bridgedeck cushions replaced in 2024.
• Hatches/ Portlights: Lewmar Ocean Series deck hatches w/Ocean Air shades and screens, and Lewmar alloy opening ports in cabins.
• Anchors: Dual bow anchor rollers
 - 55lb Rocna on starboard roller with ~50’ 5/16” HT chain and ~200’ 5/8” 8-plait rode in starboard deck locker
 - Fortress FX-37 with 5/16” chain leader and 9/16” 3-strand rode in port deck locker
• Anchor Windlasses: Lewmar V2/V3, vertical capstan and gypsy w/helm station toggle control and buttons by windlass
• Bow nets: Gray Sunrise bow nets replaced in 2022

The Multihull Source, Inc. offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
