Hull construction:
Shell – Strip plank + Cold molded Mahogany + 2x300gr/m2 E-glass
Structure – Laminated frames & beams (Mahogany & Afromosia)
Decks – Burma Teak on top of marine plywood + 300gr/m2 E-glass

Superstructure construction:
Shell – Marine Plywood + 300gr/m2 E-glass
Structure – Laminated frames & beams (Mahogany & Afromosia)
Decks – Burma Teak on top of marine plywood + 300gr/m2 E-glass

Tank construction:
Fuel Oil tanks – Stainless Steel 316L, 4mm thickness with Passivation
Fresh water tanks – High density Polyethylene
Grey water tanks ‐ High density Polyethylene
Black water tanks ‐ High density Polyethylene

Tank capacities:
Fuel oil tanks – 8851Ltr Fresh water tanks – 3288Ltr Grey water tank – 1528Ltr Black water tank – 940Ltr Holding tank – 1367Ltr Sewage tank – 1474Ltr

Floors – Afromosia Parque in all guest areas. Crew areas vinyl flooring.
Ceilings – Matte lacquer in guest and crew areas. Salon and master cabin has Racanello applications. Walls – Matte veneer varnish and matte lacquer. Corridor and master cabin has Stucco panelling.
Fixed Furniture – Matte veneer & lacquer Fabrics – Extex
Hardware/Fixtures – Turnstyles and Sugatsune in guest areas, Sugatsune and Razeto in crew area. Loose Furniture – Owners supply
Trim – Solid wood matte veneer or lacquer
Kitchen counter – Neolith calacatta gold Bathroom counters:
Guest cabin 1 ‐ Veneer and matte varnish Guest cabin 2 ‐ Neolith just white
VIP cabin – Emerald Quartz Master cabin – Multicolor Onyx Crew WC – Neolith just white
Flybridge wet bar – Neolith calacatta gold Bathroom showers – Same materials as above counters Lighting – Cantalupi LED lighting 24V (with dimmers)
Refrigerator – Siemens KG86NAID1N (Galley), 1 x Arçelik freezer (Crew mess) Outdoor refrigerator – 2 x Vitrifrigo 24V
Ice maker – Uğur soğutma UBM 20 hold capacity 1.2kg (production 20kg/24hr) Aspirator – Falmec Stella 90
Cooker – Siemens EX975KXX1E Microwave – Siemens BE525LMS0 Oven – Siemens VB558C0S0 Dishwasher – Siemens SN616X00MT
Washing machine – Siemens WA14LQH0TR Dryer – Siemens WT45W410TR
Cold storage – 2 custom cold stores Fridge or Freezer

Propulsion system & Steering:
Engines – 2 x Volvo Penta D13‐1000, 735kW (1000HP) @ 2400RPM (@ Crankshaft) Gearbox – 2 x ZF500‐1 A 2.609 reduction ratio
Thrust bearing & flexible coupling – Rubber design CTB2 & SL208 Shaft – 70mm Duplex shafts
Gas throttle – Volvo EVC kit Wheelhouse & Flybridge
Bow thruster – Side Power SAC450/386‐C‐4‐H, 28kW (38HP), 400V, 450kg continuous thrust Interceptor & Stabilizer – Humphree system with active ride control and zero speed stabilizer 24V
Fuel system:
Fuel filter – Engines Racor filter generators separ filters Piping/valve material – Geberit Mapress Stainless Steel 316L
Valves – Ball valves electronic valves in transfer system and shut off with Noah SA Type acuator, 24V
Lube & Sludge oil system:
Lube oil pump ‐ Gianneschi FQ 15 380V, 0.37kW
Fresh water system:
Water pressure pump – Gianneschi JET 518 B C.E. 24V + 230/400V, 3Ph, 50Hz 1.1kW+1.1kW Watermaker – 1 x HRO H24C SFC 1800‐2, 284ltr/Hr
Boiler – Gianneschi Boiler 100 LT 230/400V 2.8+2.8kW INOX
Hot water circulation pump – 2 x Gianneschi CB25/16 B 24V 1.1kW Piping/valve material – Girpi C‐PVC
Dirty water system:
Macerator pumps:
Black water – Gianneschi MVI60 230/400V 3Ph 50HZ 1.1kW Grey water – Gianneschi MVI60 230/400V 3Ph 50HZ 1.1kW
Tank wash pump – Gianneschi ACB 331/A B 230/400V 3Ph 50Hz 1,8kW

Toilets – 6 x Tecma Silence plus 2G, soft close, 24V, 0.72kW
Sewage treatment – Hamann Compact 0125, 3000ltr/day capacity
Piping/valve material – Girpi C‐PVC, 24V Aliaxis Valves used for Automation System
Bilge/Fire system:
Bilge pump – Gianneschi ACB531 BT 400/690V 3Ph 50Hz 5.5kW Fire pump – 2 x Gianneschi ACB431/B 24V,1.5kW
Automatic bilge pumps – 2 x Rule 3700GPH 24V Piping/valve material – Geberit Mapress CuNiFe
Valves – Ball valves, check valves. Bilge branches controlled with Noah SA Type acuator, 24V
Raw water cooling system:
Piping/valves – Geberit Mapress CuNiFe
Scupper system:
Piping – Girpi C‐PVC
Fixed fire fighting system:
System type – FM200 for engine room operable from wheelhouse
HVAC system:
Brand – Cruisair
Chiller – 3 x TWC48 DDC 3853 230V 50Hz 3Ph, 48000BTU/Hr, Total 144000BTU/Hr

Onboard electricity – 12V, 24V, 230V, 230/400V
Generators – 2 x Fischer Panda 45i PMS 36kW @ 230‐400V/50Hz 3Ph variable speed marine
generator with Centek exhaust system with muffler and water seperator
Batteries:
Engine starter batteries – 4 x Mastervolt AGM 12/160Ah (24V system) Generator starter batteries – 2 x Mastervolt AGM 12/130Ah (12V system) Service batteries – 12 x Mastervolt MVSV 2V/1250 (24V system) Emergency batteries – 2 x Mastervolt MVG 12/200Ah (24V system)
VHF batteries – 1 x Mastervolt MVG 12/200Ah 12V (12V system) Chargers:
Engine starter – 2 x Mastervolt ChargeMaster 24/80‐3 Generator starter – 2 x Mastervolt ChargeMaster 12/35‐3 Service – 2x Mastervolt ChargeMasster Plus 24/110‐2 CZone Emergency – Mastervolt ChargeMaster 24/20‐3
Invertor – 2 x Mastervolt Mass Combi Pro 24/3500‐100. The invertors can work in sync to provide 7000W of power. If service battery charger has a problem the invertör can be used to charge the service batteries.
Shore power – Custom transformer Shore connection – Marinco 65Amp

Multi functional Nav. System:
2 x Simrad MO19‐T Display (wheelhouse) 1 x Simrad MO19‐T Display (flybridge)
Other screens:
1 x Simrad IS42 Digital display (wheelhouse) 1 x Simrad IS42 Digital display (flybridge)
1 x Simrad IS42 Digital display (Captain’s cabin) Radar – Halo 4 Pulse Compression radar with 4ft array Navtex – Furuno NX300
GPS – HS80A GPS Compass antenna Echosounder – Airmar B744VL transducer
Wind indicator – Navico 120WX Ultrasonic weather station
Autopilot – Simrad AP44 autopilot controller (in wheelhouse and flybridge), NAC‐3 Autopilot VRF Core pack with Precision‐9, RF300 rudder feedback
VHF:
Simrad RS40 VHF Class‐D DSC & AIS Receiver (wheelhouse) Simrad HS40 wireless handset (flybridge)
2 x VHF 74 VHF Antenna (VHF & AIS)
AIS – Navico NAIS‐500 Class B AIS with GPS‐500 Antenna Magnetic compass – Plastimo offshore 135 compass Thermal Camera – FLIR M300C
